--- title: Choosing AS/RS Equipment description: "We look at the pros and cons of three common AS/RS modules: horizontal carousels, vertical carousels, and vertical lift modules (VLMs)." image: https://info.archon-interactive.com/hubfs/csm_Horizontal-Technical-Data_4dad2d0840.jpg --- [![](https://info.archon-interactive.com/hubfs/Archon_Interactive_August_2015/Archon_Logo.png)](http://archon-interactive.com/) - [Solutions](https://archon-interactive.com/warehouse-management/) - [Warehouse Management](https://archon-interactive.com/warehouse-management/) - [Warehouse Control](https://archon-interactive.com/warehouse-control/) - [3D Pack](https://archon-interactive.com/3d-pack/) - [3PL](https://archon-interactive.com/third-party-logistics/) - [Cycle Counting](https://archon-interactive.com/cycle-counting/) - [ERP Integration](https://archon-interactive.com/integration/) - [Resources](https://archon-interactive.com/resources/) - [Blog](https://info.archon-interactive.com/blog) - [Our Story](https://archon-interactive.com/about-us/) - [Contact Us](https://archon-interactive.com/contact/) # Warehouse Dispatch # Choosing AS/RS Equipment Posted by [Reid Curley](https://info.archon-interactive.com/blog/author/reid-curley) on Sep 6, 2016 8:00:00 AM - [Tweet](https://twitter.com/share) ![Image © Kardex Remstar](https://info.archon-interactive.com/hs-fs/hubfs/kardex-remstar-horizontal-carousel-main-2.jpg?width=295&name=kardex-remstar-horizontal-carousel-main-2.jpg "Image © Kardex Remstar")Implementing Automatic Storage and Retrieval Systems (AS/RS), or expanding your AS/RS capacity, offers great benefits to productivity—but with a meaningful upfront cost. Here we'll be looking at three common AS/RS modules: horizontal carousels, vertical carousels, and vertical lift modules (VLMs). Each has particular advantages and disadvantages. You'll need to carefully examine your warehouse environment and business needs to determine what type works best for you. Some benefits apply to all three types of equipment though. "Since all of the modules bring the goods to the person, areas of the warehouse that were previously unused for material storage are now available," says Mike Banashak of AS/RS specialist [Alternative Handling Technologies LLC](http://alternativehandlingtechnologies.com/). "This increased utilization of the cubic capacity of a building enables companies to increase their storage capacity without the need for building expansions. The work area is condensed and worker safety and ergonomics are improved." ## Horizontal Carousel ![Image © Kardex Remstar](https://info.archon-interactive.com/hs-fs/hubfs/csm_Horizontal-Technical-Data_4dad2d0840.jpg?width=400&name=csm_Horizontal-Technical-Data_4dad2d0840.jpg "Image © Kardex Remstar") Horizontal carousels bring the goods to the worker. While each individual carousel may move slower than walking pace, they work best when two to four units are combined. As the number of lines in an order and orders in a batch increases, the distance to travel between each new item is reduced, and waiting time can be reduced to seconds for each item. As the drive machinery is located inside the shelving, and adjustable shelf heights maximize the use of space, the footprint reduction can be significant. Racks are often left open but can be fenced off for security. The horizontal setup lends itself to low ceilings and large warehouse footprints; however, horizontal carousels can be stacked on top of each other to make use of vertical space. ### Advantages: - High throughput - Very high pick rates - Great storage density - Faster than vertical - Most economical ### Disadvantages: - Fixed pick heights—less ergonomic - Doesn't leverage vertical space, if available ### Best for: - High depth of inventory - Small to medium heavy items - Large batch sizes and order numbers - Large areas - Low ceilings ## Vertical Carousel ![Image © Kardex Remstar](https://info.archon-interactive.com/hs-fs/hubfs/csm_KR_004VTC_HH_67c4c7797b.jpg?width=180&name=csm_KR_004VTC_HH_67c4c7797b.jpg "Image © Kardex Remstar") Vertical and horizontal carousels operate using similar machinery. The vertical carousel's main benefit is taking advantage of [unused vertical space](https://info.archon-interactive.com/blog/floor-to-ceiling-maximizing-your-warehouse-space), resulting in an extremely small footprint—ideal when floor space is at a premium. As with horizontal carousels, positioning more than one unit together reduces picker wait times. The "box" setup is both extremely secure and lends itself to control of the environment, maintaining a certain temperature or humidity level inside the unit. Vertical carousels have lower storage density than equivalent sized horizontal carousels, but smaller footprints. ### Advantages - High throughput - Can be temperature or humidity controlled - Automatic security - Very small footprint - Ergonomic pick height ### Disadvantages - Slower than horizontal - Items must be distributed to avoid unbalanced loads ### Best for: - Heights up to 15-18 feet - Secure/controlled items - Items requiring climate control - Uniform bin sizes and shelf weights ## Vertical Lift Module (VLM) ![Image © Kardex Remstar](https://info.archon-interactive.com/hs-fs/hubfs/csm_KR_EVLM056-HH_8b411bcc36.jpg?width=200&name=csm_KR_EVLM056-HH_8b411bcc36.jpg "Image © Kardex Remstar") The most expensive of the bunch, VLMs are unparalleled for making the most of high ceilings and really packing the most storage into tiny footprints. As their drive machinery is smaller than an equivalent height vertical carousel, they can be built much higher. As with vertical carousels, the box setup offers high security and the capacity to control the climate within the unit. The linear rather than rotating movement means no unbalanced loading problems and that heavy items can be stored and retreived safely. Units can have flexible tray heights, meaning many different sizes of items can be stored without compromising on overall storage density. ### Advantages - High storage density—tiny footprint - Ergonomic pick height - Automatic security - Can be climate controlled ### Disadvantages - Lower throughput - Lower pick rate - Most expensive ### Best for: - Heights of up to 100 feet - Secure/controlled items - Items requiring climate control - Heavy items - Non-uniform sized items [![New Call-to-action](https://no-cache.hubspot.com/cta/default/755901/9598df16-b76b-40a7-a949-5c81e4652b0d.png)](https://cta-redirect.hubspot.com/cta/redirect/755901/9598df16-b76b-40a7-a949-5c81e4652b0d) Topics: [automatic storage and retrieval systems](https://info.archon-interactive.com/blog/topic/automatic-storage-and-retrieval-systems) ![Reid Curley](https://info.archon-interactive.com/hubfs/Reid-Curley.jpg) ### Written by [Reid Curley](https://info.archon-interactive.com/blog/author/reid-curley) [![New Call-to-action](https://no-cache.hubspot.com/cta/default/755901/1b224f23-bb5e-4d63-9d22-5ba41c542945.png)](https://cta-redirect.hubspot.com/cta/redirect/755901/1b224f23-bb5e-4d63-9d22-5ba41c542945) ### Subscribe to Email Updates ### Categories - [warehouse efficiency (70)](https://info.archon-interactive.com/blog/topic/warehouse-efficiency) - [warehouse management system (29)](https://info.archon-interactive.com/blog/topic/warehouse-management-system) - [warehouse management software (25)](https://info.archon-interactive.com/blog/topic/warehouse-management-software) - [Cycle Counting (22)](https://info.archon-interactive.com/blog/topic/cycle-counting) - [warehouse replenishment (14)](https://info.archon-interactive.com/blog/topic/warehouse-replenishment) - [warehouse management (10)](https://info.archon-interactive.com/blog/topic/warehouse-management) - [warehouse efficiency software (4)](https://info.archon-interactive.com/blog/topic/warehouse-efficiency-software) - [warehouse productivity (4)](https://info.archon-interactive.com/blog/topic/warehouse-productivity) - [automatic storage and retrieval systems (2)](https://info.archon-interactive.com/blog/topic/automatic-storage-and-retrieval-systems) - [Warehouse Safety (1)](https://info.archon-interactive.com/blog/topic/warehouse-safety) - [warehouse staffing (1)](https://info.archon-interactive.com/blog/topic/warehouse-staffing) see all ### Recent Posts ### Search Search Our Site ![Archon-footerlogo2](https://info.archon-interactive.com/hubfs/Archon-footerlogo2.jpg "Archon-footerlogo2") We specialize in providing customer-specific efficient solutions, ranging from relatively simple equipment control applications to our customized full-blown, enterprise class Warehouse Management System, WaveTrak WMS®. Our satisfied customers include small manufacturers and distributors, 3PL providers and Global 1000 companies. Quick Links: - [ERP Integration](https://archon-interactive.com/integration/) - [Resources](https://archon-interactive.com/resources/) - [Blog](https://info.archon-interactive.com/blog) - [Our Story](https://archon-interactive.com/about-us/) - [Contact Us](https://archon-interactive.com/contact/) Services: - [Warehouse Management](https://archon-interactive.com/warehouse-management/) - [Warehouse Control](https://archon-interactive.com/warehouse-control/) - [3PL](https://archon-interactive.com/third-party-logistics/) - [3D Pack](https://archon-interactive.com/3d-pack/) - [Cycle Counting](https://archon-interactive.com/cycle-counting/)
